gnadmin | GN Decanter Centrifuge

GN sludge vacuum pump

A couple day ago, GN completed the assembly and factory test of one set solids vacuum pump and sent them to the loading port. The equipment will be transported to the overseas clients.

Waste vacuum pump, also named as solids transfer pump. It is a pneumatic slurry transfer vacuum pump for liquid, slurry, and solids transfer. With special structure design, it can be used at tough environmental for solids transfer, high working performance and less maintenance. The pump can transfer material with high gravity and high density, solids content max. up to 80%.

In some working areas such as mine sites, some mud and other mud-water mixtures will be generated during the mining process, occupying a large amount of working area and needing to be cleaned up in time. This kind of cleaning work needs a kind of equipment with strong conveying capacity and easy to move, and GN solid vacuum pump is fully capable of this work. In addition to conveying slurry, GN solid vacuum pump can also be used for cleaning sludge at the bottom of tanks, conveying grain, conveying construction slurry and so on.

For more information on GN solids vacuum pump, please feel free to contact GN Separation.

GN sludge vacuum pump

A couple day agon, GN Separation produced and shipped a batch of decanter centrifuges and inclined plate clarifier for mud dewatering projects.

When you need separate solid /liquid mixtures with high solids content, you can choose a decanter centrifuge.Decanter centrifuges can be optimally adjusted for specific applications. Applications range from sludge dewatering to classification or wet classification to solid classification.

Three phase decanter centrifuge is widely used in dewatering project. We have different model due to the handling capacity, the smallest model is GNLW-224FT, and the bigget model is GNLW-764FT.

Decanter Centrifuge Function

1)Dewatering sludge / mud and suspensions

2)Thickening sludge or mud

3)Clarifying different type liquids

4)Separating 3-phase mixtures, i.e. two immiscible fluid phases and a solid phase

5) Classifying solids in a wet suspension by grain size

6) Separation of solids according to various densities

GN can not only provide users with Dewatering Decanter Centrifuges, rely on GN rich production line of separation and conveying equipment.

For more information on GN three-phase decanter centrifuge, no hesitate to contact GN Separation.

Decanter centrifuge

GN has designed, developed and produced different kinds of centrifuges for solid/liquid and liquid/liquid separation.

GN clarifying decanter centrifuge is C series decanter centrifuge with beach angle of 20 degree. It suits for material of small particle size, low density difference between solids and liquid, moderate viscosity, moderate concentration.

The smallest model is 224FT which is come with 220MM Bowl Diameter and the max G force is 3200G, The beach angle of the C series clarifying decanter centrifuge is 20 degree, so the bowl cone section is short, and the straight section of the bowl is longer, it will give the bowl to have a longer clarifying section.

GN can not only provide users with high-tech Clarifying Decanter Centrifuge, but also provide users with Clarifying Disc Separator with high rotating speed and G force is up to 12000 G, which can carry out multi-step clarification treatment for users’ materials, so as to achieve the most desired effect for customers.

For more information on 3-phase decanter centrifuge package, please feel free to contact GN Separation.

GN decanter centrifuge

This month, GN will attend the ECWATECH 2023 Exhibition held in Moscow.

GN will be provided a platform for all the water treatment supplier to communication. Welcome to GN booth to get more information.

This time, GN will show the equipment as below

Decanter centrifuge– GNLW series decanter centrifuge has the bowl diameter from 9 inch to 30 inch for different flow rate requirements. GN decanter is widely used in waste water treatment and other industries separation application.

2. Solid vacuum pump, it is 100% pneumatic driving and make it suitable for the harzard and explosive environment. The max particle size is 50MM, The pump is designed for both automatic operation and manually operation. Operator only needs to adjust the suction and discharge time by twisting the switch on the panel.

For more information on the mining tailing dewatering centrifuge, please feel free to contact GN Separation.

sludge vacuum pump

GN solid control is a professional supplier of various oilfield equipment, including oil drilling and service equipment, oil production equipment, OCTG, wellhead & downhole tools and spare parts. Our products have already been exported to USA, South America, Africa, Middle East, Russia and some other countries (regions).

We have 3 models GNSP-40B, GNSP-20B and GNSP-10B, The maximum transport capacity of the three models for clean water is 10 cubic meters, 20 cubic meters and 40 cubic meters respectively. According to different material conditions, suction and discharge height and distance, the conveying capacity will be different. Generally, the lower the material density, the lower the viscosity and the shorter the conveying distance, the higher the working efficiency of the equipment will be.

Now contact GN Separation to obtain the quotation and technical solution of solids vacuum pump for free. Spot sales can meet the requirements of fast delivery.
