As this winner seems to be colder than before, the consumption for gasoline becomes more. Drilling activities in North Europe, North American and China becomes more activated. While the labor cost for drilling always goes up, so these big drilling companies and petroleum companies seriously look for solutions to lower financial cost.

Shale Shaker Screen is a high consumed product, which installed on the shale shaker, generally the operators shall change the screen at least every week, but cost for those Original Brands’ Shaker Screen is too much money, so all the end user prefer to find reliable and qualified replacement screens, with less financial cost.

GN Solids Control is a professional manufacturer of Shale Shaker Screen, and we understand that cost-effective shale shaker screens are very important for solids control equipment. So GN focus on researching and developing the best technology to manufacture top quality shaker screens for our clients.

GN replacement Shaker Screen are available for all API no., and can be used for Derrick, MI-Swaco, and Brandt shale shakers.

GN achieved the API RP 13 C test reports for whole series, from API 20, 35, 40……3000. Now GN is able to make around 8000 PCs of shaker screens every month, and with our distribution network and cost-effective products, GN Shale Shaker Screens are popular  around the world.

GN Screen Type
Hook strip flat screen
Steel frame screen
Composite frame screen
Pyramid screen
Hook strip soft screen
And more…
GN Replacement Screen
Original Screen for GN Solids Control shaker
Replacement screen for Derrick Shaker
Replacement Shaker Screen for MI-Swaco Shaker
Replacement Screen for NOV Brandt Shaker
And more……

Welcome to contact us for Shale Shaker Screen requirement, and it’s acceptable for sample orders. And we have our own Big Warehouse in Houston, TX, USA for stocking big amounts of screens.



Best & Regards,

Kevin Liu

Regional Manager

Tel:+86-316-5276988/9  Fax:+86-315-5276990
Mob(WhatsApp/Wechat): +86-15810901775
Email: kevin@gnseparation.com

Dredging Material Treatment is always a big problem for local governments, especially for De-watering the material.

GN Solids Control can supply One Stop, Turnkey Solution for Dredging Material Treatment.

Last week, GN 1000 GPM dredging slurry separation system was delivered to work site for customer’s project starting celebration. It is the first unit standard configuration system for dredging slurry separation which showed that GN has made herself getting into a further level for river and lake sludge cleaning up.

Main Equipments for 1000GPM Dredging Slurry Separation System,
1. GNZS703 Shale shaker – 2 Units
2. GNZJ703-2S De-sander – 1 Unit
3. GNSB6x5-13 Sand Pump – 2 Units
4. Mud tank and accessories

Working Procedure,
The Dredging Slurry firstly go through the shale shakers, in order to remove the solids with more than 100 um. The slurry after the Shale Shaker Treatment would go through the De-Sander, in order to remove the the solids between 45~70 um. There are independent mud tanks under the shale shaker and De-sander, for collecting the liquid separately passing from the shale shaker and De-sander.

The two sand pumps are used for feeding material into the Shake Shaker and De-sander Separately.

GN also develops Decanter Centrifuge for removing fine solids (up to 5um) from liquid, and removing all the Solids from Liquid, with Polymer Dosing System.

Welcome to contact us if you need more information.

GN Solids Control CO.

Kevin Liu

What is Hydro Excavation?

Hydro Excavation is now popular in North America for excavating soil by High Pressurized Water. Then an air conveyance or vacuum is used to transfer the mixture of water, soil, large size trash and some other materials into a debris tank. This Hydro Excavation allows for a non-destructive to excavate soil and locate underground utilities.

How to deal with the Hydro Excavation Waste Slurry Treatment?

GN Solids Control provides One Stop, Turn Key Solution to recover water and discharge the soil suitable for environment. The process diagram is as below.

1. Waste Collecting and Washing Module – the waste slurry is delivered to site via the hydro truck and then discharged to a large size collecting hopper at which bottom there are valves to discharge the slurry onto a coarse screen for large size trash separation.

The liquid with fine particles is collected in the tank located under the coarse screen. The liquid is then pumped to GN high G force drying shaker for finer solids separation. Here the operator can also use pressure flushing device to wash the slurry. GN shaker is fixed with composite frame shaker screen for longer working time and better performance.

2. Fine Solids Hydro cycling Separation Module – GN desilter with hydro cyclone manifold is fixed on a washing tank for further separation of the fine solids. The under shaker of the desilter is same model with GN drying shaker for easy maintenance. The hydro cyclone is using centrifugal force and gravity to separate the liquid and solids. The slurry is pumped into the cyclone with high speed for effectively separation process.

3. Dewatering Centrifuge Module – in this hydro excavation waste slurry treatment system, a decanter centrifuge (bowl diameter is 9 inch, 220mm) is used to remove the ultra-fine solids in the slurry. A chemical dosing system can be connected to the dewatering centrifuge to increase the efficiency of the separation.

Welcome to contact us for more detailed information.



GN Solids Control

Kevin Liu

kevin@gnseparation.com

Shale Shaker Screens are widely used for Shale Shakers and Mud Cleaners.

Generally the screens shall be changed every 300~400 working hours, but that depends on the detailed project information. It is a Big Cost for the drilling companies/contractors or Solids Control Companies to purchase Shale Shaker Screens, especially when they buy the Original Screens from those reputable famous brands.

GN Solids Control understands the cost-effective shale shaker screens are very important for the solids control equipment.

So GN keeps researching and developing the best technology for manufacturing the Top Quality shaker screens for our clients. Now one of the major business of GN Solids Control is Shale Shaker Screen, and GN is able to manufacture around 8000 PCs of shaker screens every month. With our distribution network and cost-effective products, GN Shale Shaker Screens are popular around the world.

GN Screen Type
Hook strip flat screen
Steel frame screen
Composite frame screen
Pyramid screen
Hook strip soft screen
And more…

GN Replacement Screen
Original Screen for GN Solids Control shaker
Replacement screen for Derrick Shaker
Replacement Shaker Screen for MI-Swaco Shaker
Replacement Screen for NOV Brandt Shaker
And more……

What API Size Shaker Screen available from GN

D 100 Separation(Micron) API Screen Number
>1850.0 TO 2180.0 API 10
>780.0 TO 925.0 API 20
> 462.5 TO 550.0 API 35
> 390.0 TO 462.5 API 40
> 275.0 TO 327.5 API 50
> 231.0 TO 275.0 API 60
> 196.0 TO 231.0 API 70
> 165.0 TO 196.0 API 80
> 137.5 TO 165.0 API 100
> 116.5 TO 137.5 API 120
> 98.0 TO 116.5 API 140
> 82.5 TO 98.0 API 170
> 69.0 TO 82.5 API 200
> 58.0 TO 69.0 API 230
> 49.0 TO 58.0 API 270
> 41.5 TO 49.0 API 325

Hereby GN would like to emphasis that we have big stocking in the North American and China Mainland, the clients can receive the screens from us within two months, wherever they are.

Welcome to contact us if you need sample, test report or RFQ.

After participation in the CIPPE 2018 in Beijing, China from 27th to 29th March, 2018, GN solids control will participate in OTC 2018 in Houston , TX. For more information of CIPPE 2018, pls check : http://www.gnsolidscontrol.com/drilling-fluids/welcome-to-gn-booth-for-the-2018-cippe-beijing-oil-show


We welcome you to visit GN at CIPPE 2018 in Beijing and visit GN factory where is 30km from the exhibition center during the oil exhibition.
OTC 2018 general information: for more information, pls visit their website: http://2018.otcnet.org/
Show Time & Location: 30 April – 3 May, 2018. NRG Park, Houston, Texas, USA
Booth No. 1: NRG Center 1369-1 (GN China)
Booth No. 2: NRG Arena 8000 (GN America)
What equipments will GN show at OTC?


Decanter centrifuge GNLW363C, this is the best sold model decanter centrifuge among all the decanter centrifuge models.
Shale shaker: GNZS594F-HB, we have many sets of shale shaker and mud cleaner in stock in Houston warehouse for immediate shipment, we install Martin brand vibration motor made in USA and assembly in our warehouse.
Sludge Vacuum pump:GNSP-20A, this is our new products in 2018, we have sold GNSP-40A vacuum pump for drilling cuttings transfer and dredging slurry transfer for dredging slurry separation system, sometimes the vacuum pump may not be suitable to transfer the oil sludge based on the sludge density and viscosity and the depth. GNSP-10A & GNSP-20A vacuum pump is the new designed model to meet the client’s requirement for smaller treating capacity.


Mud cleaner: GNZS594E-2S12N
Centrifugal pump, the installation dimension, outer dimension and spare parts are all interchangeable with Mission Magnum centrifugal pump.
